Description
The 1N5408 is a 3A general-purpose rectifier diode, commonly used in applications such as DC-DC converters, AC-DC converters, voltage switching, clamping circuits, power supplies, and voltage regulators. It features an average forward current of 3A, a forward voltage drop of 1V, and a non-repetitive peak current of 200A. Additionally, it has a peak reverse current of 10µA and is designed for high-voltage applications with a maximum repetitive reverse voltage of 1000V.
Specifications
-
Diode Type: General-purpose rectifier diode
-
Diode Number: 1N5408
-
Average Forward Current: 3A
-
Forward Voltage Drop: 1V @ 3A
-
Non-Repetitive Peak Current: 200A
-
Peak Reverse Current: 10µA
-
Repetitive Reverse Voltage: 1000V
-
Package Type: DO-201
